Astral XP High Performance Pool & Spa Pump Range

Astral XP High Performance Pool & Spa Pump Range

The Astral XP is a high-flow, high-pressure pool pump range designed and manufactured in Australia. It replaces Astral's older BX pumps with improved efficiency and a more robust, durable design, moving more water while using less power and running fewer hours per day. Built to run cooler with less fan noise, the XP suits high-density residential locations where quiet operation matters. Available in five variants: 1.5HP, 2.0HP and 3.0HP in single phase, plus 2.0HP and 3.0HP in three phase.

Key Features

• High flow and high pressure for demanding pool and spa equipment
• Increased efficiency over the older BX range, moving more water with less power
• Designed to run cooler with reduced fan noise
• Robust, durable design with low maintenance requirements
• Australian designed and manufactured
• Five variants across single-phase (240V) and three-phase (400V) supplies

Specifications

Spec	XP 1.5	XP 2.0	XP 3.0	XP 2.0 3PH	XP 3.0 3PH
Product Code	21615	21620	21630	21623	21633
Horsepower	1.5HP	2.0HP	3.0HP	2.0HP	3.0HP
Voltage / Phase	240V Single	240V Single	240V Single	400V Three	400V Three
Input Power	1,500W	1,900W	2,500W	2,400W	3,200W
Max Flow Rate @ 8m head	440 L/min	540 L/min	635 L/min	540 L/min	635 L/min
Full Load Amps	7A	8.1A	11A	3.4A	4A
Country of Manufacture	Australia

Which Size Do I Need?

The right XP size depends on your pool volume, plumbing and the demands of your equipment, such as in-floor cleaning, spa jets, water features or a large filter. The 3-phase models suit properties with a three-phase supply, typically larger or commercial-scale installations. If you're not sure which size or supply type suits your setup, get in touch and we'll help you choose.

Frequently Asked Questions

Does the XP replace the older BX pump?
Yes. Astral's XP range replaces the older generation BX pumps with increased efficiency and a more robust design.

What's the difference between the single-phase and three-phase models?
Single-phase models run on a standard 240V supply, while three-phase models need a 400V three-phase supply. Check your property's supply with your electrician before choosing.

Is the XP pump quiet?
The XP is designed to run cooler with less fan noise, making it a good fit for high-density residential locations where low noise is important.

Is the XP pump made in Australia?
Yes. The XP range is Australian designed and manufactured.
